Mechanical Design

Mechanical Design

Allowing product manufacturers to develop design information effectively from their conceptual ideas, we bring design and drafting solutions for mechanical components and industrial equipment’s to meet shop floor requirements.
Having delivered design and drafting solutions for diversified industrial domains, Matrical Technologies has a proven track record of successfully executing complicated design projects within the expected turnabout time. We offer pliable engagement models with strict consent to non-confessional agreement to meet manufacturer specific requirements and cost structures, allowing better control over product design and development process.
Our design cycle follows the standard procedure: Concept design, Concept selection, Preliminary design, and Detailed design for efficient project management.

Some of the verifications performed as per the services are:

  • Layers as per your standards.
  • Scale as per your requirement.
  • CAD standards like line thickness, line type, arrow type, text height nomenclature, general notes, arrows and dimension text etc. are verified according to the requirements.
  • Title Block in relevance to drawing.
  • Dimensions with the respect to input.
  • Loadings & Load combinations as per relevant codes.
  • Design calculations.
  • Check elements for failure.
  • Material Property.
